Specifications
1 GB GH3030/ 3435XH78THigh Temperature Alloy
2 good price from factory
3 MTC
GH3030 high temperature alloy
GH3030 solid solution strengthening type high temperature alloy is the early development of ni - cr solid solution strengthening 20 80 type high temperature alloy, the chemical composition is simple, under 800 ℃ has satisfactory heat intensity and high plasticity, and has good oxidation resistance, thermal fatigue, cold stamping and welding performance. Alloy after solid solution treatment for single-phase austenitic, stability in use process organization. Main products are cold rolled sheet, also can supply the rod, ring, wire and tube products such as deformation. To be used for production work under 800 ℃ of turbine engine combustion chamber components and under 1100 ℃ antioxidant but other high temperature load is small parts. [1] GH3030 has strong thermal and cold properties, used to make all kinds of chemical equipment and related accessories
Chinese name GH3030 Material mark GH3030 (GH30) Similar brand 3-435,XH78T (Russia) The melting temperature range of 1374 ~ 1420 ℃
2. Chemical Composition
| C |
Cr |
Ni |
P |
S |
Fe |
Si |
Al |
Ti |
| max 0.12 |
19.0-22.0 |
balance |
max 0.03 |
max 0.02 |
1.5 |
max 0.8 |
max 0.15 |
0.15-0.35 |
3.Product Application Areas:
Our products have been used in all kinds of areas,such as aviation,aerospace,navigation,nuclear energy,chemical industry,
electronic information,achine manufacture, petrochemical,automotive,instrument and meter, Communication ,transportation, and medical instruments, etc.
